RED DSMC OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC 955-0020_V5.2, REV-G | 63
FRAMED OVERLAY
The video display is scaled down on the monitor so that the overlay items fit outside of the video area rather
than over it. This setting only affects the monitor, and not affect captured footage.
AUTO HIDE MENUS
Hides the Upper Status Row and Lower Status Row. When this option is disabled, the video is scaled so that
the menus are not overlaid on the video. When this option is enabled, the video is not scaled. This options lets
creates a control surface on a monitor without to scaling the video. This setting only affects the monitor, and
not recorded footage.
To toggle display/hide the menus when Auto Hide Menus is enabled, perform either of the following actions:
Press the Menu button on the DSMC Side Handle.
Tap the touchscreen.
NOTE: Enabling this option on a non-control surface results in the menus never displaying on that monitor.
Framed Overlay
Auto Hide Menus
