11. Once the tool is moved to the center of the materials and stopped, the engraving area can be verified and
adjusted by using the direction key button. At this time, check the laser pointer while moving it for easier
measurement and adjustment.
Whenever the direction key is pressed, move the laser pointer to the left, top, right
and bottom of the area to show the area to be engraved. Check out whether the
area to be engraved is out of the materials surface. If so, adjust the location by
using the direction key.
The laser pointer moves the area to be engraved to the left, top, right or bottom
according to current location. If the current location of the laser pointer is left, then,
press key to move the area to the left.
14. After location of engraving is decided, press and hold button until it beeps (more than 3 seconds) to
start the engraving.
15. Close the engraver cover.
Work Area
