8.2.13
Compare File->Device (Complete Device)
This mode would compare the data in the device flash (starting at the device start address) to the
corresponding data in the file. The process would only stop once the entire device had been checked, or
differences were found. Areas that are not covered by the file would be assumed to be 0xFF and would
therefore require a corresponding blank area on the device to be verified correctly.
8.2.14
Compare File->Device (File Data Only)
This mode would compare the data in the file to the corresponding data on the device. This is identical in
behaviour to the after-write readback verify process. Areas not covered by the file would not be checked.
Typically this will be a faster operation, as the entire flash does not have to be uploaded, however, it is
therefore a less thorough process.
8.3 Workspace Properties
Invoked from the Workspace pop-up menu item Properties.... See also section 8.1.1.4.
The ‘Workspace Properties’ dialog box shows details of:
•
The Workspace Name
•
The filename and path
•
The time and date when the workspace was last saved
Figure 8-6 Workspace Properties
