Printing Functions

-Features

• You cannot use both the closed and diagonal line method on the same com-

mand sheet.

• There is no limit to the number of areas you can designate on a single com-

mand sheet.

• If you use Outline mode for letter images with a thickness of less than 3mm,

0.12", the print image might come out as expected.
