Bit Switches - 4
SM 115 D418
Fax Option
Type 9001
D418
G3 Switch 04 (SP No. 1-105-005)
No Function Comments
sender that training has succeeded.
4-7 Not used Do not change the settings.
G3 Switch 05 (SP No. 1-105-006)
No Function Comments
0-3 Initial Tx modem rate (kbps)
These bits set the initial starting modem
rate for transmission.
Use the dedicated transmission
parameters if you need to change this for
specific receivers.
If a modem rate 14.4 kbps or slower is
selected, V.8 protocol should be disabled
manually.
Cross reference
V.8 protocol on/off - G3 switch 03, bit 2
Bit 3 Bit 2 Bit 1 Bit 0 kbps
0 0 0 1 2.4
0 0 1 0 4.8
0 0 1 1 7.2
0 1 0 0 9.6
0 1 0 1 12.0
0 1 1 0 14.4
0 1 1 1 16.8
1 0 0 0 19.2
1 0 0 1 21.6
1 0 1 0 24.0
1 0 1 1 26.4
1 1 0 0 28.8
1 1 0 1 31.2
1 1 1 0 33.6
⇒
Rev. 07/27/2011
