PM Tables
SM Appendix 2-3 D062/D063/D065/D066
Appendix:
PM Tables
Development Unit
300K 450K 600K AN Exp. Note
Developer R PM cycle is 350K.
Development Filter R I
Development Roller C Dry cloth
Side Seals C C Blower brush, dry cloth
Entrance Seal C C Blower brush, dry cloth
Toner Hopper C C Dry cloth
Toner Bottle Holder C C Dry cloth
Toner Trap C C Dry cloth
Drive Gears C C Blower brush.
Development Roller
Drive Shaft
C C
Clean with blower brush
and dry cloth every time
the developer is
replaced.
Development Unit C C Dry cloth.
Paddle Roller Shaft C C Blower brush, dry cloth.
Used Toner Separation
Unit
I R
Paper Feed
300K 600K 1000K AN Exp. Note
Registration Rollers C Alcohol
Relay Rollers C Alcohol
Paper Dust Mylar C C Dry cloth
