LG/B4 Feeder Kit (B474)
D062/D063/D065/D066 2-30 SM
2.5 LG/B4 FEEDER KIT (B474)
2.5.1 ACCESSORY CHECK
Check the accessories and their quantities against this list:
Description Q"ty
1. Cover 1
2. B4/LG frame 1
3. Bottom plate extension 1
4. Rear bracket 1
5. Front bracket 1
6. Harness clamp 1
7. Tapping hex screws - M4 x 8 6
8. Tapping screws - M4 x 8 4
