REPLACEMENT AND ADJUSTMENT
B513/B53
1 24
SM
3.9
JOGGER UNIT B513 (OPTION)
3.9.1
JOGGER UNIT
1.
Remove the jogger unit cover [A] (
x 2).
2.
Remove the jogger unit [B] (
x 2,
x 1).
B513I002.
W
MF
B513R003.
W
MF
[A]
[B]
862
864
