REPLACEMENT AND ADJUSTMENT
SM 25 B513/B531
Output
Jogger Unit/
Punch Unit
B513/B53131
3.9.2 JOGGER UNIT PCB
1. Remove the jogger unit from the finisher. ( 3.9.1)
2. Remove the jogger unit control PCB [A] ( x 2, x 3).
B513R001.WMF
[A]
