Key Card Bracket (B498), Key Counter Bracket (B452)
D062/D063/D065/D066 2-90 SM
2.16 KEY CARD BRACKET (B498), KEY COUNTER
BRACKET (B452)
2.16.1 KEY CARD BRACKET B498 ACCESSORIES
Check the accessories and their quantities against this list.
Description Qty
1. Key Card Table 1
2. Harness Clamp 1
3. Tapping Screws (M3 x 8) 4
4. Tapping Screws (M4 x 14) 2
5. Stud 1
6. Decal 1
7. Key Card Table Support 1
