USB2.0/SD Slot Type C (D464)
D062/D063/D065/D066 2-102 SM
2.19 USB2.0/SD SLOT TYPE C (D464)
2.19.1 ACCESSORIES
Description Q"ty
1. USB2.0/SD Slot Type C 1
2. USB Cable 1
3. Tapping Screw 2
4. Screw 1
5. Decal 1
2.19.2 INSTALLATION
1. Rear upper cover ( p.4-8 "Rear Covers")
2. Right upper cover (
p.4-7 "Right Covers")
3. Left upper cover (
p.4-8)
4. Operation Panel (
p.4-6)
Rev. 08/03/2009
