Ricoh Aficio MP 7001 SP Service Manual

Skew Adjustment
SM 79 D454
Multi-Folding
Unit FD5000
D454
The black arrow shows the direction of paper feed from right to left. When the skew sheet is
opened the Front edge is shorter than the Rear edge.
Skew Correction Reference Diagrams and Table
Skew Correction Reference Diagrams
Key
Symbol/Color What It Means
{
Stopper 1 needs adjustment

Stopper 2 needs adjustment
}
Stopper 3 needs adjustment
Blue line
Peak fold (points left)
Green line
Valley fold (points right)
