D454 118 SM
2.5.4 PAPER TRANSPORT MOTORS
1. Horizontal Transport Motor 7. 2nd Fold Motor
2. Top Tray Exit Motor 8. 1st Fold Motor
3. Top Tray Transport Motor 9. Fold Plate Motor
4. Dynamic Roller Lift Motor 10. Registration Roller Release Motor
5. Crease Motor 11. Dynamic Roller Transport Motor
6. FM6 Pawl Motor 12. Registration Roller Transport Motor
