Input/Output Check
SM Appendix 4-261 D062/D063/D065/D066
Appendix:
Service
Program
Mode Tables
Reading
6140 Bit Description
0 1
6140 48 Exit Jogger HP Sensor: Rear Not used in the machine
6140 49 Exit Jogger HP Sensor: Upper Not used in the machine
*1: Combination of DIP SW 1 and SW 2
DIP SW 1 DIP SW 2 Punch Type
0 0 Japan
1 0 Europe
0 1 North America
1 1 North Europe
*2: Please refer to "Lower Tray (B804 Only)" in the Service Manual for the "2000/3000
(Booklet) Finisher".
4.2.6 FINISHER 1 OUTPUT CHECK: SP6124
6124 Finisher Output Check: Finisher 1 (Finisher D373/D374)
001 Entrance Motor
002 Upper Feed Motor
003 Lower Feed Motor
004 Exit Motor
005 Knock Roller Motor
006 Shift Motor
007 Exit Guide Plate Open / Close Motor
008 Tray Lift Motor
009 Stack Roller Motor
Turn on the electrical components of
the finisher individually for test
purposes.
To Next Page
