Tray Movement Mechanism
D373/D374 48 SM
Lower Tray Full Condition Table
A3 (DLT)
1 Sht 2 Sht 3 Sht 4 Sht 5 Sht 6 Sht 7 Sth 8 Sht 9 Sht
Full 1
3 Cnt
Full 2
5 Cnt
15
Cnt
Full 3
7 Cnt
13
Cnt
4 Cnt 2 Cnt 2 Cnt 2 Cnt
A4 (LT)
1 Sht 2 Sht 3 Sht 4 Sht 5 Sht 6 Sht 7 Sth 8 Sht 9 Sht
Full1
16
Cnt
Full 2
10
Cnt
10
Cnt
15
Cnt
20
Cnt
15
Cnt
10
Cnt
8 Cnt 8 Cnt
Full 3
Examples:
After the copier makes a booklet with 1 sheet of A3/DLT paper, the machine checks every
100 ms for the ‘Full 1’ condition. If the Full 1 condition occurs 3 times, the machine detects
that the tray is full.
After the copier makes a booklet with 5 sheets of A4/LT paper, the machine checks every
100 ms for the ‘Full 2’ condition. If the Full 2 condition occurs 20 times, the machine detects
that the tray is full.
