Error Codes
SM 33 D418
Fax Option
Type 9001
D418
Code Meaning Suggested Cause/Action
Replace the FCU or the NCU.
4-10
Communication failed
because of an ID Code
mismatch (Closed
Network) or Tel. No./CSI
mismatch (Protection
against Wrong
Connections)
Get the ID Codes the same and/or the CSIs
programmed correctly, then resend.
The machine at the other end may be
defective.
5-10 DCR timer expired Replace the FCU.
5-20
Storage impossible
because of a lack of
memory
5-21 Memory overflow
Temporary memory shortage.
Test the SAF memory.
Replace the FCU or optional EXMEM board
5-23
Print data error when
printing a substitute rx or
confidential rx message
Test the SAF memory.
Ask the other end to resend the message.
Replace the FCU or optional EXMEM board.
5-25 SAF file access error Replace the FCU or EXMEM board.
6-00
G3 ECM - T1 time out
during reception of
facsimile data
6-01
G3 ECM - no V.21 signal
was received
6-02
G3 ECM - EOR was
received
Try adjusting the rx cable equalizer.
Replace the FCU or NCU.
6-04
G3 ECM - RTC not
detected
Check the line connection.
Check connections from the NCU to the FCU.
Check for a bad line or defective remote
terminal.
Replace the FCU or NCU.
