Page #1047 background imageLoading...
Page #1047 background image
Error Codes
D418 34 SM
Code Meaning Suggested Cause/Action
6-05
G3 ECM - facsimile data
frame not received within
18 s of CFR, but there
was no line fail
Check the line connection.
Check connections from the NCU to the FCU.
Check for a bad line or defective remote
terminal.
Replace the FCU or NCU.
Try adjusting the rx cable equalizer
Cross reference
Rx cable equalizer - G3 Switch 07 (PSTN)
6-06
G3 ECM -
coding/decoding error
Defective FCU.
The other terminal may be defective.
6-08
G3 ECM - PIP/PIN
received in reply to
PPS.NULL
The other end pressed Stop during
communication.
The other terminal may be defective.
6-09 G3 ECM - ERR received
Check for a noisy line.
Adjust the tx levels of the communicating
machines.
See code 6-05.
6-10
G3 ECM - error frames
still received at the other
end after all
communication attempts
at 2400 bps
Check for line noise.
Adjust the tx level (use NCU parameter 01 or
the dedicated tx parameter for that address).
Check the line connection.
Defective remote terminal.
6-21
V.21 flag detected during
high speed modem
communication
The other terminal may be defective or
incompatible.
6-22
The machine resets the
sequence because of an
abnormal handshake in
the V.34 control channel
Check for line noise.
If the same error occurs frequently, replace the
FCU.
Defective remote terminal.
6-99 V.21 signal not stopped Replace the FCU.
