Controller Options
D017/D018/D019/D020/D084/D085 2-89 SM
Installation
No. Name Description
4 TEL1 Jack for telephone connection
5 Line 2 Jack for a 2nd line connection to the Fax Interface Unit
(D361) (G3) when this option is installed.
6 Board Slot Optional interface boards are installed here.
7 SD Card Slot 1 For options provided on SD cards. The application SD
card (with the exception of the HDD Encryption unit or VM
SD card) should be installed in Slot 1. If more than one
application is to be used, move the applications to the
same SD card with SP5873.
8 SD Card Slot 2 For options provided on SD cards and servicing. The VM
application, HDD Encryption Unit and Browser Unit SD
cards must be installed in Slot 2 (lower). However, HDD
Encryption Unit and Browser Unit SD cards do not need to
be kept in SD slot 2 (these can be removed after
installing).
9 USB-B Built-in for connection of USB devices (USB 2.0)
10 Ethernet Standard LAN connection point. 100BaseT LAN
11 Green LED Lights when the network is connected and operating.
12 Orange LED Indicates the current transmission speed:
ON: 100Base
OFF: 10Base
Only two SD Card slots are available for applications.
To install more applications, they must be moved onto one SD Card. (See Moving an
Application to Another SD Card)
