Ricoh D017 - 4. Appendix: Service Program Mode Tables

System SP Tables-1
SM Appendix 4-1 D017/D018/D019/D020/D084/D085
Appendix:
Service
Program
Mode
4. APPENDIX: SERVICE PROGRAM MODE
TABLES
4.1 SYSTEM SP TABLES-1
4.1.1 SP1XXX: FEED
1001* Leading Edge Registration
1 Tray Adjusts the printing leading edge registration
from each paper feed station using the Trimming
Area Pattern (SP2902 Pattern No. 10).
[+9.0 to –9.0 / +0.0 / 0.1 mm/step]
Use the
key to toggle between + and –
before entering the value.
The specification is 3 ± 2 mm.
See "Replacement and Adjustment - Copy
Adjustment" for details.
2 By-pass
3 Duplex Side2
1002* Side-to-Side Registration
1 Tray 1
Adjusts the printing side-to-side registration from
each paper feed station using the Trimming Area
Pattern (SP2902 Pattern No. 10).
[+9.0 to –9.0 / +0.0 / 0.1 mm/step]
Use the
key to toggle between + and – before
entering the value. The specification is 2 ± 1.5
mm. See "Replacement and Adjustment - Copy
Adjustment" for details.
2 Tray 2
3
Tray 3 (Optional PFU
Tray 1, or LCT)
4
Tray 4 (Optional PFU
Tray 2)
5 By-pass
6 Duplex Side 2
