Bit Switches - 6
D361/D510 152 SM
IP Fax Switch 05 (SP No. 1-111-006)
No. Function Comments
0-3
Modem bit rate setting for transmission
(kbps)
Sets the modem bit rate for
transmission. The default is "0110"
(14.4K bps).
Bit 3 Bit 2 Bit 1 Bit 0 kbps
0 0 0 1 2.4
0 0 1 1 4.8
0 0 1 1 7.2
0 1 0 0 9.6
0 1 0 1 12.0
0 1 1 0 14.4
0 1 1 1 16.8
1 0 0 0 19.2
1 0 0 1 21.6
1 0 1 0 24.0
1 0 1 1 26.4
1 1 0 0 28.8
1 1 0 1 31.2
1 1 1 0 33.6
