1000-Sheet Booklet Finisher (B793)
D017/D018/D019/D020/D084/D085 2-53 SM
Installation
2. Open the front door [A] of the 1000-sheet booklet finisher, and then pull out the jogger
unit [B].
3. Remove all tapes and packing materials from the inside of the finisher.
4. Attach the cushions [A] to the finisher.
Make sure that the cushions are placed within 0 to 1 mm [B] from the edge of
the cover or frame.
5. Install the ground plate [C] on the finisher [D] (
x 2; M3x8).
To Next Page
