System Service Mode
SM Appendix 9-207 D037/D038/D040/D041
Appendix:
SP Mode
Tables
003 3 -
004 4 -
5792 [ECS Debug SW]
001 1 -
5801 [Memory Clear] (Refer to IMPORTANT NOTE in Sect. 5.8)
001 All Clear
Resets all correction data for process control and
all software counters, and returns all modes and
adjustments to their default values.
002 Engine [ENG] Clears the engine settings.
003 SCS
Initializes default system settings, SCS (System
Control Service) settings, operation display
coordinates, and ROM update information.
004 IMH Memory Clr -
005 MCS -
006 Copier application Initializes all copier application settings.
007 Fax application
Initializes the fax reset time, job login ID, all TX/RX
settings, local storage file numbers, and off-hook
timer.
008 Printer application
The following service settings:
Bit switches
Gamma settings (User & Service)
Toner Limit
The following user settings:
Tray Priority
Menu Protect
System Setting except for setting of Energy
Saver
⇒
Rev. 05/21/2009
