Ricoh G179 - Sp6-XXX: Peripherals

SP6-xxx: Peripherals-1
SM 5-91 G179
Service
Tables
5.15 SP6-XXX: PERIPHERALS-1
Punch Position: Sub Scan
6128
Adjusts the punching position in the sub scan direction. (For B805)
001 2-Hole: JPN
002 3-Hole: NA
003 4-Hole: EU
004 5-Hole: SCAN
005 2-Hole: NA
006 1-Hole: JPN
[-7.5 to 7.5 / 0 / 0.5 mm]
Punch Position: Main Scan
6129
Adjusts the punching position in the main scan direction. (For B805)
001 2-Hole: JPN
002 3-Hole: NA
003 4-Hole: EU
004 4-Hole: SCAN
005 2-Hole: NA
006 1-Hole: JPN
[-2 to 2 / 0 / 0.4 mm]
Skew Corr: Buckle Adj.
6130*
Adjusts the paper buckle at the punch unit for each paper size. (For B805)
001 A3 SEF
002 B4 SEF
003 A4 SEF
[-5 to 5 / 0 / 0.25 mm]
