Ricoh G179 - Lower Transport Motor; Upper Transport Motor and Exit Motor

MOTORS
B408 4 SM
1.3.3 UPPER TRANSPORT MOTOR AND EXIT MOTOR
1. Rear cover (

1.1)
2. Motor assembly [A] (

x 4,

x 2)
3. Upper transport motor [B] (

x 4)
4. Exit motor [C] (

x 4)
1.3.4 LOWER TRANSPORT MOTOR
1. Main PCB (

1.1)
2. Lower transport motor [A] (

x 2,

x
1)
B408R112.WMF
B408R111.WMF
[A]
[B]
[C]
[A]
