Duplex Unit
G179 6-44 SM
6.11.4 DUPLEX OPERATION
Up to A4/LT (81/2" x 11") LEF
There are three sheets of paper in the paper feed path at the same time. The interleave
method is used.
The drawing above shows the paper movement with the interleave method for three sheets
of paper. The printing is done as follows:
From A4/LT (8 1/2" x 11") LEF to 400mm length
There are two sheets of paper in the paper feed path at the same time. The interleave
method is used. For sheets longer than 400 mm, there is no interleaving.
The drawing above shows the paper movement with the interleave method for two sheets
of paper. The printing is done as follows:
To Next Page
