2.Mechanism
18
Category Specification
card) and the SMC (in the report for the Smart Operation Panel).
Network
• Wireless LAN
802.11b/g/n
• Bluetooth
Bluetooth4.0
Audio input/output Monaural speaker 1ch (output: 1 to 2 W), Microphone
RTC accuracy ±52.56 seconds per month (using external crystal oscillator, 20 ppm)
Hard keys
• Extended Feature keys (EX1, EX2, and EX3)
Use for startup in extended mode etc.
• Control panel reboot key
Use to reboot the control panel when it freezes.
LED types
• Main power indicator (blue)
Lights when the power is on. Flashes slowly in Sleep mode.
• [Check Status] indicator lamp (red/blue)
Lights when an error occurs.
• Data In indicator (blue)
Flashes when the machine receives data from a printer driver or LAN-Fax driver.
• Fax indicator (blue)
Flashes while sending or receiving a fax. Lights when there is a received fax
document in the fax memory.
• Media access lamp (blue)
Lights when there is an SD card inserted in the SD card slot.
Maximum power
consumption
4 W or less
(excluding external interfaces and internal feature expansions)
Power
consumption in
Sleep mode
0.35 W or less
(When in Sleep mode, power is not supplied to USB devices connected to the USB
slots.)
Specification comparison with the previous model
Item This model Previous model
Appearance
Control panel size
(Width × Height)
267 × 160 mm 345 × 161 mm
CPU operating frequency 1 GHz 533 MHz
RAM size 2 GB 1 GB
