NFC Card Reader Type M13 (D3AC-21)
114
Installation Procedure
This section includes the procedure for a machine that has no 1-Bin Tray Unit option. However, this procedure
can be used for a machine that has a 1-Bin Tray Unit installed.
• Turn OFF the main power and unplug the power cord from the wall socket. If installing without
turning OFF the main power, an electric shock or a malfunction may occur.
1. Open the right cover.
2. Remove the front right cover [A] and hinge cover [B].
3. Remove the connector cover [A] on the operation panel.
To Next Page
