Anti-condensation Heater (for Mainframe Paper Tray)
87
Installation Procedure
• Do not lift the machine together with one or more paper feed unit(s):
If there is already a machine with one or more optional paper feed unit(s), be sure to disconnect the
machine and paper feed unit(s), and lift them up separately when moving/transporting. Otherwise, the
handle of the paper feed unit will break due to the mainframe’s weight, and it can cause an injury.
• Turn OFF the main power and unplug the power cord from the wall socket. If installing without
turning OFF the main power, an electric shock or a malfunction may occur.
• Do the following procedure to prevent the harnesses from being damaged.
• Check that harnesses are not damaged or pinched after installation.
1. Attach the two locating pins [A] [B] on the table.
2. Attach the heater bracket [A]. ( × 2)
• Pass the connector through the hole in the table.
To Next Page
