Ricoh MP C407

Bypass
297
3. Remove the two screws. ( × 2)
4. Remove the bypass feed unit [A].
• Lift up the left side of the unit and remove it while pulling it out forward.
Bypass Paper End Sensor
1. Remove the bypass feed unit. (Bypass Feed Unit)
