3.SP Mode Tables
306
evenly among the printers on the network, and allows files to moved around, combined, and
converted to different formats.
PC Personal Computer
PGS Pages. A page is the total scanned surface of the original. Duplex pages count as two pages, and
A3 simplex count as two pages if the A3/DLT counter SP is switched ON.
PJob Print Jobs
Ppr Paper
PrtJam Printer (plotter) Jam
PrtPGS Print Pages
R Red (Toner Remaining). Applies to the wide format model A2 only. This machine is under
development and currently not available.
Rez Resolution
SC Service Code (Error SC code displayed)
Scn Scan
Sim,
Simplex
Simplex, printing on 1 side.
S-to-Email Scan-to-E-mail
SMC SMC report printed with SP5-990. All of the Group 8 counters are recorded in the SMC report.
Svr Server
TonEnd Toner End
TonSave Toner Save
TXJob Send, Transmission
YMC Yellow, Magenta, Cyan
YMCK Yellow, Magenta, Cyan, Black
Abbreviation What it means
• All of the Group 8 SPs are reset with SP5-801-001 (Memory All Clear).
SP8-XXX (Data Log2) -1
SP No. Large Category Small Category ENG or CTL [Min to Max/Init./Step]
8-001-001 T:Total Jobs CTL* [ 0 to 99999999 / 0 / 1 ]
8-002-001 C:Total Jobs CTL* [ 0 to 99999999 / 0 / 1 ]
8-003-001 F:Total Jobs CTL* [ 0 to 99999999 / 0 / 1 ]
8-004-001 P:Total Jobs CTL* [ 0 to 99999999 / 0 / 1 ]
8-005-001 S:Total Jobs CTL* [ 0 to 99999999 / 0 / 1 ]
8-006-001 L:Total Jobs CTL* [ 0 to 99999999 / 0 / 1 ]
