Ricoh MP C407

Paper Feed
292
6. Remove the paper feed sensor [B]. (Hook × 2)
Tray Paper End Sensor
1. Remove the waste toner bottle. (Waste Toner Bottle)
2. Remove the tray paper end sensor [A]. ( × 1, hook × 2)
When reattaching the tray paper end sensor, make sure that the shaft of the feeler is hooked onto the
bracket [A].
