Controller Options
154
2. Install the file format converter [A] into the slot and then fasten it with screws.
3. Plug in and turn on the main power switch.
4. Check or set the following SP codes with the values shown below.
SP No. Title Setting
SP5-836-001 Capture Function (0:Off 1:On) "1"
SP5-836-002 Panel Setting "0"
5. Make sure that the machine can recognize the option (see Check All Connections at the end of this
section).
IEEE 1284 Interface Board Type M19 (D3C0-17)
• Turn OFF the main power and unplug the power cord from the wall socket. If installing without
turning OFF the main power, an electric shock or a malfunction may occur.
You can only install one of the following network interfaces at a time:
• File Format Converter
• IEEE 1284 Interface Board
• IEEE 802.11a/g/n Interface Unit
