3.SP Mode Tables
27
• Turn the machine off and on. Tell the administrator that you have completed servicing the machine.
• The Administrator will then set the "Service Mode Lock" to ON.
Remarks
Display on the Control Panel Screen
The maximum number of characters which can show on the control panel screen is limited to 30 characters. For
this reason, some of the SP modes shown on the screen need to be abbreviated. The following are abbreviations
used for the SP modes for which the full description is over 20 characters.
Item Description
Paper Weight Plain Paper1: 60-74 g/m
2
, 16-20lb.
Plain Paper2: 75-81 g/m
2
, 20lb.
Middle Thick: 82-105 g/m
2
, 20-28lb.
Thick Paper1: 106-169 g/m
2
, 28lb. Bond-90lb.
Thick Paper2: 170-220 g/m
2
, 65-80lb.
Thick Paper3: 221-256 g/m
2
, 80lb. Cover-140lb.
Paper Type N: Normal paper
MTH: Middle thick paper
TH: Thick paper
Paper Feed Station P: Paper tray
B: Bypass table
Color Mode
[Color]
[K]: Black in B&W mode
[Y], [M], or [C]: Yellow, Magenta, or Cyan in Full Color mode
[YMC]: Only for Yellow, Magenta, and Cyan
[FC]: Full Color mode
[FC, K], [FC, Y], [FC, M], or [FC, C]: Black, Yellow, Magenta, or Cyan in full color
mode
Print Mode S: Simplex
D: Duplex
Process Speed L: Low speed (89 mm/s)
M: Middle speed (178 mm/s)
Others
The following symbols are used in the SP mode tables.
FA: Factory setting
(Data may be adjusted from the default setting at the factory. Refer to the factory setting sheets enclosed. You can
find it under the jammed paper removal decal.)
