Ricoh MP C407 User Manual

IC Card Reader (External Option)
112
4. Cut out the hole for the USB cable to pass through the scanner rear cover [A].
5. Pass the USB cable from the IC card reader through the hole in the scanner rear cover, and then reassemble
the machine.
6. Attach the clamps [A] to prevent the cable from sagging.
7. Connect the USB cable to the USB connector at the left of the mainframe as shown above. Either
connector can be used.
• Obtain these clamps [A] in advance, because they are not included in this kit.

Ricoh MP C407 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (B/W)	42 ppm
Print Speed (Color)	42 ppm
Max Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Monthly Duty Cycle	150, 000 pages
Paper Size	A4, A5, B5
Connectivity	USB, Ethernet, Wi-Fi
Mobile Printing	Apple AirPrint, Google Cloud Print, Mopria
Operating System Compatibility	Windows, Mac OS, Linux
