Controller Options
165
4. Ping the “RX” + “MAC address” from the command prompt, on a windows PC which is on the same
network as the mainframe.
• When installing the USB Device Server Option Type M19, the installation status is not shown on
the Configuration Page.
What Do the LED Indications Mean?
When this option is properly installed and recognized by the main machine, the LED indicators light up under
the following conditions.
No. Light Color Lights Up When:
1 Green and Yellow 1000BASE-T operates
2 Green 10BASE-T operates
3 Yellow 100BASE-TX operates
Notes for Energy Save Mode Setting
If the machine which has this option enters into the energy save mode, you cannot print because there will be a
communication error. Follow the instructions below to disable the machine’s entering the energy save mode.
1. Press [Features Settings] on the operation panel.
2. Press [Administrator Tools] in [System Settings].
To Next Page
