Image Adjustment
195
Y)
3 Shadow (High
ID)
(K, C, M, and
Y)
Adjust the offset value so that the density of level 11 matches
that of level 11 on the C-5Y chart.
4 Highlight
(Low ID)
(K, C, M, and
Y)
Adjust the offset value so that dirty background does not
show on the copy and the density of level 3 is slightly lighter
than that of level 3 on the C-5Y chart.
- Text (Letter) Mode, Single Color -
Item to
Adjust
Level on the C-5Y chart
(K)
Adjustment Standard
1 ID max: (K)
Adjust the offset value so that the density of level 13 matches
that of level 13 on the C-5Y chart.
2 Middle
(Middle ID)
(K)
Adjust the offset value so that the density of level 7 matches
that of level 7 on the C-5Y chart.
3 Shadow (High
ID) (K)
Adjust the offset value so that the density of level 11 matches
that of level 11 on the C-5Y chart.
4 Highlight
(Low ID) (K)
Adjust the offset value so that dirty background does not
show on the copy and the density of level 3 is slightly lighter
than that of level 3 on the C-5Y chart.
• Text parts of the test pattern cannot be printed clearly after you adjust "shadow" as shown above. At
this time, check if the 5 line/mm pattern at each corner is printed clearly. If it is not, adjust the offset
value of "shadow" again until it is.
Printer Mode
There are six adjustable modes (select these modes with printer SP1-102-001):
• 1200 x 1200 photo mode (1bit/4col)
• 600 x 600 photo mode (4bit/4col)
• 600 x 600 photo mode (2bit/4col)
• 600 x 600 photo mode (1bit/4col)
• 1200 x 1200 text mode (1bit/4col)
• 600 x 600 text mode (4bit/4col)
• 600 x 600 text mode (2bit/4col)
• 600 x 600 text mode (1bit/4col)
K C M Y
Highlight SP1-104-001 SP1-104-021 SP1-104-041 SP1-104-061
