Ricoh MP C407 User Manual

ADF
226
7. Remove the gear bracket [A].
8. Remove the two gears [A].
Do not remove the gear [B], to prevent the inner pin [C] from dropping into the machine.
9. Open the ADF unit [A] while holding the gear [B] by hand, and open the scanning guide plate (rear side)
[C] by pulling the release lever [D].
• Hold the gear [B]. It is not fixed, and may drop into the machine.
• Open the scanning guide plate (rear side) [C] before replacing the CIS unit. Otherwise, the
surface could be damaged.

Ricoh MP C407 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (B/W)	42 ppm
Print Speed (Color)	42 ppm
Max Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Monthly Duty Cycle	150, 000 pages
Paper Size	A4, A5, B5
Connectivity	USB, Ethernet, Wi-Fi
Mobile Printing	Apple AirPrint, Google Cloud Print, Mopria
Operating System Compatibility	Windows, Mac OS, Linux
