SC1xx: Scanning
414
SC1xx: Scanning
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
SC101-01 D LED error
The peak white level is less than the prescribed value.
This SC is detected when the machine adjusts the LED’s light intensity or before just
scanning.
• Loose connector
• Defective scanner carriage
• Defective BiCU
• Damaged harness (FFC)
• Dirty or incorrect white plate
Check if the SC occurs by turning the power OFF then ON. If the SC occurs again, do the
following steps. Check if the SC reoccurs by cycling the power after each step.
1. Reconnect the following connectors:
SBU-BiCU harness (FFC) connector
SBU-LEDB (scanner lamp board) harness (FFC) connector (SBU)
2. Check the white plate (Exposure glass).
Clean or replace the white plate if damaged.
3. Replace the scanner carriage
4. Replace the BiCU.
5. Replace the harness (FFC).
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
SC101-02 D LED error (LED illumination adjustment)
The peak white level is less than the prescribed value.
This SC is detected when the machine adjusts the LED’s light intensity.
• Defective LED
• LED driver error
• Disconnected connectors or damaged harness (power/signal)
Check if the SC occurs by turning the power OFF then ON. If the SC occurs again, do the
following steps. Check if the SC reoccurs by cycling the power after each step.
1. Reconnect the connectors (power/signal).
2. Replace the scanner carriage
3. Replace the harness (power/signal).
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)

Ricoh MP C407 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (B/W)	42 ppm
Print Speed (Color)	42 ppm
Max Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Monthly Duty Cycle	150, 000 pages
Paper Size	A4, A5, B5
Connectivity	USB, Ethernet, Wi-Fi
Mobile Printing	Apple AirPrint, Google Cloud Print, Mopria
Operating System Compatibility	Windows, Mac OS, Linux
