Ricoh MP C407

Electrical Component Defects
521
Fuse
Name
Connector (Out) Capacity Voltage Part No. Part Name Replaceable
FU5 CN613-2 (5V) 5A 250V 11071351 SCT5A No
FU102 N/A (Protecting the voltage
converter circuit in the PSU)
10A 250V 11071388 FIH 250V
10A(EM)8A03
No
FU101 N/A (Protecting the fusing
circuit in the PSU)
15A 250V 11071241 TCL-15A-N4 Yes
FU103 CN600-4,5 (Anti-condensation
Heater)
2A 250V 11071362 SCT2A No
200V (Mainly EU)
Fuse
Name
Connector (Out) Capacity Voltage Part No. Part Name Replaceable
FU1 CN611-1 (24V) 10A 250V 11071393 51MS(P)-100H
GF-009
No
FU2 CN610-1 (24VL) 10A 250V 11071393 51MS(P)-100H
GF-009
No
FU3 CN610-2 (24VL_LPS) 4A 250V 11071360 SCT4A No
FU4 CN611-3 (24V_LPS) 4A 250V 11071393 51MS(P)-100H
GF-009
No
FU5 CN613-2 (5V) 5A 250V 11071351 SCT5A No
FU102 N/A (Protecting the voltage
converter circuit in the PSU)
8A 250V 11071366 FIH 250V
8A(EM)8A03
No
FU101 N/A (Protecting the fusing
circuit in the PSU)
8A 250V 11071366 FIH 250V
8A(EM)8A03
No
FU103 CN600-4,5 (Anti-condensation
Heater)
1A 250V 11071367 SCT1A No
