Ricoh MP C407 User Manual

Fusing
574
Fusing Mechanism
Callout Item Callout Item
[A] Stay [D] Fusing Sleeve Belt (Diameter: 25)
[B] Fusing Lamp [E] Nip Pad
[C] Reflector [F] Pressure Roller (Diameter: 25
The fusing unit uses the QSU system. (QSU: Quick Start Up).
The heat from the fusing lamp [B] is reflected by the reflector [C] and heats the fusing sleeve belt [D].
The temperature at both ends of the fusing lamp is lower than the middle.
The fusing sleeve belt itself has no drive mechanism; the pressure roller drives it. The nip pad [E] at the sleeve
belt side is pushed against the pressure roller and keeps the nip width on the sleeve belt.

Ricoh MP C407 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Speed (B/W)	42 ppm
Print Speed (Color)	42 ppm
Max Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Monthly Duty Cycle	150, 000 pages
Paper Size	A4, A5, B5
Connectivity	USB, Ethernet, Wi-Fi
Mobile Printing	Apple AirPrint, Google Cloud Print, Mopria
Operating System Compatibility	Windows, Mac OS, Linux
