Loading Paper into the Paper Tray
The method of loading paper varies for each tray type.
• When replacing paper or removing jammed paper, make sure not to trap or injure your fingers.
D0CPIC1361
Tray 1
*1
Tray 2
Tray 3
Wide LCT
*5
Large capacity tray (LCT)
*4
Interposer
Multi bypass tray (Tray A)
*6
Two-tray wide LCT
*7
Twin interposer
Bypass tray
*2*3
*1
The A3/11 × 17 tray unit can be attached.
*2
The banner paper guide tray can be attached.
*3
This is unavailable if the two-tray wide LCT is attached.
*4
The extension unit of LCT can be attached.
*5
The banner sheet guide tray can be attached.
*6
The banner sheet tray of multi bypass tray (Tray A) can be attached.
*7
The banner sheet tray of two-tray wide LCT can be attached.
• Before loading paper into a tray, check the paper size and type that can be loaded in the tray,
and confirm the paper size that is automatically detected.
page 241 "Recommended Paper Sizes and Types"
Loading Paper into the Paper Tray
197
