Ricoh Pro C5310S - Page 217

To Next Page

To Previous Page

D0CPIC1377

2. Set the end fence.

D0CPIC1378

1. End fence

2. Extender

To remove the end fence, slide it to the right by pressing the stopper down.

D0CPIC1379

Loading Paper into the Paper Tray

215
