Ricoh SP 3710DN Field Service Manual

5.System Maintenance
150
Fax Service Test (Only for Fax Models)
Fax Service Test Menu
Entering the Fax Service Test Menu
Turn on the machine while pressing the [Home] key, and hold on pressing it until displayed "Fax Service
Test".
Selecting an Item
Select the item which you want to execute.
Exiting the Fax Service Test Menu
Press [Exit].
Menu List
Menu
Description
Off-Hook Test
On Hook
Executes the on hook test.
Off Hook
Executes the off hook test
CED Test
Executes the CED test.
CNG Test
1100 Hz
Executes the CNG test
ANSam Test
Executes the ANSam test.
Ring Tone Test
Executes the ring tone test.
DTMF Test
Tone [0] to [9]
Executes the DTMF tone 0 to 9 test.
Tone [*]
Executes the DTMF tone * test.
Tone [#]
Executes the DTMF tone # test.
Tone Stop
Executes the Stop DTMF tone test.
Modem Test
[V34] 33600 Bps
Generates the [V34] 33600 bps signal.
[V34] 28800 Bps
Generates the [V34] 28800 bps signal.
[V17] 14400 Bps
Generates the [V17] 14400 bps signal.
[V17] 12000 Bps
Generates the [V17] 12000 bps signal.
[V17] 9600 Bps
Generates the [V17] 9600 bps signal.
[V17] 7200 Bps
Generates the [V17] 7200 bps signal.
[V29] 9600 Bps
Generates the [V29] 9600 bps signal.
[V29] 7200 Bps
Generates the [V29] 7200 bps signal.
[V27] 4800 Bps
Generates the [V27] 4800 bps signal.
[V27] 2400 Bps
Generates the [V27] 2400 bps signal.
[V21] 300 Bps
Generates the [V21] 300 bps signal.

Ricoh SP 3710DN Specifications

General

Color	No
Duplex printing	-
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	32 ppm
Printer fonts	PCL, PostScript
Printing colors	Black
Maximum duty cycle	- pages per month
Page description languages	PCL 5e, PCL 6, PostScript 3
Total input capacity	300 sheets
Total output capacity	125 sheets
Maximum input capacity	550 sheets
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.72 W
Power consumption (printing)	- W
Sustainability compliance	Yes
Sustainability certificates	ENERGY STAR
Sound pressure level (printing)	- dB
Product color	Black, White
Market positioning	Home & office
USB connector	USB Type-B
USB 2.0 ports quantity	1
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Server operating systems supported	Windows Server 2008, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1
Included cartridge capacity (black)	7000 pages

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	262 mm
