4.Replacement and Adjustment
36
Rear Cover
1. Open the rear cover [A].
2. Slide the shaft [B] in the direction of the blue arrow, and remove the rear cover [A].
Right Cover
1. Remove the front cover (Front Cover).
2. Remove the rear cover (Rear Cover).
3. Remove the three screws of the right cover [A].
To Next Page
