Ricoh SR5050 - Page 145

Preparation
• Booklet unit (page 29)
Motor Base Plate
1. Remove cover [A] ( x2).
2. Disconnect sensor bracket [A] and harness [B] ( x1, x2, x1).
1. Replacement and Adjustment
144
