User’s Guide for DM3058
2-42
Statistic Measurement
The Statistic function is for DC voltage, AC voltage, DC current, AC current,
resistance, frequency/period, and capacitance measurement.
The front panel can display the statistical data for any set of readings: average
(Ave), maximum (Max), minimum (Min), and which can read with All function and
the number of samples taken (Total).
Press  Statistic, the display shows:
Figure 2-61 Stat. Math
Table 2-16 Statistic Measurement Menu Function Description
Function
Menu
Settings
Description
MAX
(Maximum)
Maximum value from a set of measurements.
MIN
(Minimum)
Statistical measurement all reading Min value.
AVG
(Average)
Statistical measurement all reading Average
value.
All
The complete a set of measurement.
ON
Open the selected statistic measurement
Save all changes, back to a higher level menu.
