RIGOL
User’s Guide for DM3058
To Measure Frequency and Period
The Frequency or Period of a signal could be obtained by Secondary Function
during testing its Voltage or Current or by Function button . The following
practice provides a guide to get familiar with the Frequency and Period
Measurement technique.
To Measure Frequency
Operating Steps:
1. Connect test leads as shown in figure 2-30. Red test lead connects with
Terminal HI; Black test lead connects with Terminal LO.
Figure 2-30 Sketch map for connecting
2. Press to enter into the following interface.
Figure 2-31 Frequency Measurement Interface
