RIGOL
User’s Guide for DM3058
Table 2-10 Frequency Test Characteristics
200mV, 2V, 20V, 200V, 750V
750VRMS on all ranges (HI Terminal)
3. Set the relative value (Optional).
Press REL to open or close Relative operation function. When it is open, “REL”
is shown over the screen and the reading displayed is a relative value which
comes from the result of Actual measurement vale reduces selected value.
(For the details about how to set, please refer to” Math” in Chapterer2.)
4. Read measurement value
Freq Function is set as” Slow”, 5.5 digits resolution.
5. View History data
Press History to enter into the following interface and check the data getting
from this measurement and saved.
Figure 2-32 View interface of History information
There are three types of way for viewing historical date: “Info”,” List” and “HistoG”.
Press Save after checking. By pressing Update, the History information will be
refreshed to be current newest information.
