Chapter 5 Specifications RIGOL
DP800 User Guide 5-1
Chapter 5 Specifications
All the specifications are guaranteed when the instrument has been working for more
than 30 minutes under the specified operation temperature.
Note: Unless otherwise noted, the specifications are applicable to all the channels of
the specified model.
DC Output (0℃ to 40℃)
Channel (Range)
Voltage/Current
OVP/OCP
DP832
CH1
CH2
CH3
0 to 30V/0 to 3A
0 to 30V/0 to 3A
0 to 5V/0 to 3A
10mV to 33V/1mA to 3.3A
10mV to 33V/1mA to 3.3A
10mV to 5.5V/1mA to 3.3A
DP831
CH1
CH2
CH3
0 to 8V/0 to 5A
0 to 30V/0 to 2A
0 to -30V/0 to 2A
10mV to 8.8V/1mA to 5.5A
10mV to 33V/1mA to 2.2A
-10mV to -33V/1mA to 2.2A
DP822
CH1
CH2
0 to 20V/0 to 5A
0 to 5V/0 to 16A
10mV to 22V/1mA to 5.5A
10mV to 5.5V/1mA to 16.8A
DP821
CH1
CH2
0 to 60V/0 to 1A
0 to 8V/0 to 10A
10mV to 66V/10mA to 1.1A
10mV to 8.8V/10mA to 11A
DP813
Range1
Range2
0 to 8V/0 to 20A
0 to 20V/0 to 10A
10mV to 8.8V/10mA to 22A
10mV to 22V/10mA to 11A
DP811
Range1
Range2
0 to 20V/0 to 10A
0 to 40V/0 to 5A
10mV to 22V/10mA to 11A
10mV to 44V/10mA to 5.5A
Load Regulation Rate ±(Output Percentage+Offset)
Voltage
<0.01%+2mV
Current
<0.01%+250μA
Linear Regulation Rate ±(Output Percentage+Offset)
Voltage
<0.01%+2mV
Current
<0.01%+250μA
Ripples and Noise (20Hz to 20MHz)
Normal Mode Voltage
DP831/DP832/DP822/DP821: <350μVrms/2mVpp
DP813/DP811: <350μVrms/3mVpp
Normal Mode Current
<2mArms
Annual Accuracy
[1]
(25℃±5℃)±(Output Percentage+Offset)
Channel
Programming
Readback
Voltage
Current
Voltage
Current
