RIGOL Chapter 1 Quick Start
1-16 DP800 User Guide
User Interface
DP800 series power supply provides three kinds of display modes (normal, waveform
and dial). The default is normal. You can press Display  Disp Mode to select
different display mode. This section introduces the user interface layout under the
normal display mode (as shown in the figure below and
Table 1-4 on the next page).
Figure 1-6 User Interface (Normal Display Mode)
1 2 3 4 5
6
7
8
9
10
11
